VISCOPOWER F 570 FKMo R33
for pumping viscous media of up to 30,000 mPas out of drums, for industrial applications.
- Item no.
- 10-45790002
- EAN
- 4260387214193
- Motor type
- F 457
- Max. flow rate
- 21 l/min
- Max. discharge head
- 40 mWk
- Rated output
- 0.8 kW
- Supply voltage
- 230-240 V
- Material
- Stainless steel
Immersion length
- 1000 mm
- 1200 mm
typeco
- F 570 1000 R33
- F 570 1200 R33
Overview
Fully-prepared progressive cavity pump kit containing gear unit version of the VISCOPOWER F 570 progressive cavity pump for pumping viscous media of up to 30,000 mPas out of 200-l drums. The VISCOPOWER progressive cavity pump has been designed especially for industrial applications and runs with low turbulence, under constant pressure and delivers gentle, pulsation-free pumping. The set contains the following components: VISCOPOWER progressive cavity pump (1000 mm), F 457 commutator motor, chemicals and food hose, discharge spout and compression gland.
Benefits
- Large viscosity range can be covered
- Perfectly suitable for viscous, free-flowing media but also media that is sensitive to shearing
- Pumps at constant pressure
- Can be individually adapted to media characteristics
- Pump can be dismantled and cleaned quickly and easily
- Effective use of media and high level of efficiency
Technical data
Performance
- Max. flow rate
- 21 l/min
- Max. discharge head
- 40 mWk
- Max. viscosity
- 30,000 mPas
- Suction side
- Stator housing standard version
Electrical
- Cooling
- internal ventilated
- Rated output
- 0.8 kW
- Protection class
- IP 24
- Speed control
- no
- Supply voltage
- 230-240 V
- Motor type
- F 457
- Cable length
- 5,00 m
- Frequency
- 50-60 Hz
- Type plug
- CEE 7/17-plug
- Undervoltage prot.
- yes
Materials and sealing
- Seal material
- FKM
- Type hose line
- food / chemistry hose
- Material
- Stainless steel
Dimensions and weight
- Weight
- 12.5 kg
- Immersion length
- 1,000 mm
- Outer diameter
- 53,00 mm
- Hose length from
- 2,5 m
- Nominal diameter
- DN 32 mm
Approvals
- For use in hazardous areas
- No
- FDA approval
- no
- Food approval
- no
Set components
Hand Nozzles
Materials and sealing
- Inliner
- yes
- Material inside
- ultra-high-molecular PE white
- Stator material
- PTFE
Other
- Pump
- Exzenterschneckenpumpe VISCOPOWER
- Type code
- F 570 1000 FKMo FKM SP TS R33 PTFE G16
Compare the versions
Only the properties that differ are shown.
| Property | VISCOPOWER F 570 FKMo R33This page | VISCOPOWER F 570 FKMo R33 |
|---|---|---|
| Item no. | 10-45790002 | 10-45790003 |
| Immersion length | 1,000 mm | 1,200 mm |
| Weight | 12.5 kg | 13.2 kg |
Media
This product is suitable for 166 media. The list is a guide for common applications.
A
- Ammonium nitrate10% · 20-40 °C
- Ammonium nitrate50% · 20-40 °C
- Ammonium phosphate10% · 20-40 °C
- Ammonium sulphate10% · 20 °C
- Ammonium sulphate10% · 40 °C
- Amyl alcohol100% · 20 °C
- Amyl alcohol100% · 40 °C
- Arsenic acid10% · 20-40 °C
- Arsenic acid80% · 20-40 °C
B
- Benzaldehyde100% · 20 °C
- Benzaldehyde100% · 40 °C
- Benzine100% · 20 °C
- Benzine100% · 40 °C
- Benzoic aldehyde30% · 20 °C
- Benzole100% · 20 °C
- Bicarbonate of soda10% · 20 °C
- Bicarbonate of soda10% · 40 °C
- Borax10% · 20-40 °C
- Borax100% · 20-40 °C
- Boric acid10% · 20-40 °C
- Boric acid100% · 20-40 °C
- Butanedioic acid50% · 20-40 °C
- Butanol100% · 20 °C
- Butyl alcohol100% · 20 °C
Is your medium not listed? Other media are often possible too. Request a quote and we will advise you personally.
Downloads
Data sheets
Manuals
Declarations of conformity
Drawings and diagrams
Inquiry forms
Accessories and related
Accessories
Retaining bracket
