Drum and container pumps

FP 430 Ex S-41/38 FOOD | FFKM

with mechanical seal, for pumping out of IBCs. Made from stainless steel, FFKM seal.

Item no.
10-43029612
  • ATEX
  • FDA
  • FOOD
Max. flow rate
240 l/min
Max. discharge head
13 mWk
Material
Stainless steel

Immersion length

Overview

The FP 430 drum pump can be used universally for a huge range of different media and is suited to pumping out of IBCs (immersion length 1200 mm). It is ideal for tasks where the medium is changed frequently and when working with media that cures, dries quickly or crystallises. The design featuring a mechanical seal to cover the inner tube means that the drum pump can be quickly and easily dismantled into its two main components. This makes good cleaning possible. The stainless steel versions of the drum pump have explosion protection. If necessary, it can be combined with different motors.

Benefits

  • FOOD variant (suitable for contact with food in accordance with EC 1935/2004 and FDA CFR 21)
  • Ideal for tasks where the medium is changed frequently and when working with media that cures, dries quickly or crystallises
  • Can be quickly and easily dismantled into its two main components for cleaning
  • Improved service life when working with abrasive media compared with a sealless pump
  • Can be operated temporarily against a closed valve (pump nozzle, ball cock, etc.), up to stated max. operating temperature
  • Quiet operation with particularly low levels of vibration

Technical data

Performance

Max. flow rate
240 l/min
Max. discharge head
13 mWk
Max. viscosity
1,000 mPas

Materials and sealing

Material impeller
stainless steel
Seal material
FFKM
Material
Stainless steel
Material shaft
stainless steel
Mechanical seal
PTFE/carbon, oxide ceramics, S, FFKM

Dimensions and weight

Weight
3.71 kg
Connection outlet
clamp 1 1/2"
Outer diameter
41,00 mm
Immersion length
1,200 mm

Approvals

3-A version
No
Ex marking
Ex II 1/2 G Ex h IIB T4 Ga/Gb
For use in hazardous areas
Yes
FDA approval
CFR 21
Food approval
EC 1935/2004

Other

Type impeller
axial impeller 38 for higher delivery rate
Drum pump type
FP 430

Compare the versions

Only the properties that differ are shown.

PropertyFP 430 Ex S-41/38 FOOD | FFKMFP 430 Ex S-41/38 FOOD | FFKMFP 430 Ex S-41/38 FOOD | FFKMThis page
Item no.10-4302960710-4302961010-43029612
Immersion length700 mm1,000 mm1,200 mm
Weight2.4 kg3.19 kg3.71 kg

Media

This product is suitable for 246 media. The list is a guide for common applications.

A

Is your medium not listed? Other media are often possible too. Request a quote and we will advise you personally.

Downloads

Data sheets

Manuals

Declarations of conformity

Drawings and diagrams

Inquiry forms

Other documents
