Drum and container pumps

FP 425 Ex S-41/34 | FFKM

for 99.98 % residual & container emptying. Made from stainless steel, FFKM seal.

Item no.
10-42529113
  • ATEX
Max. flow rate
220 l/min
Max. discharge head
13 mWk
Material
Stainless steel

Immersion length

Overview

When using the FP 425 drum pump (with mechanical seal to cover inner tube, immersion length 1200 mm), less than 0.05 l of residue is left in a 200-l drum, i.e. a maximum of 0.02 %. The drum pump has a built-in backflow valve which can be closed with ease using two adjusting levers before removing the drum pump from the container. This prevents the medium in the drum pump from flowing back into an emptied drum. This enables optimum use to be made of particularly expensive media and, when working with problematic media, spares the operator additional costs for cleaning drums and disposal. The drum pump is made from stainless steel; it can therefore also be used in areas subject to explosion hazards. If necessary, the drum pump can be combined with different motors.

Benefits

  • Optimum residual emptying leaving e.g. less than 0.05 l of residue in a 200-litre drum
  • No 'tipping' to fully empty the drum
  • Reduction in drum cleaning and/or disposal costs
  • optimum use of costly fluids
  • Medium is not lost when transferring the pump from one drum to the next
  • Can be operated temporarily against a closed valve (pump nozzle, ball cock, etc.), up to stated max. operating temperature
  • Stainless steel version can be used in areas subject to explosion hazards

Technical data

Performance

Max. flow rate
220 l/min
Max. discharge head
13 mWk
Max. viscosity
1,200 mPas

Materials and sealing

Material impeller
ethylene tetrafluoroethylene
Seal material
FFKM
Material
Stainless steel
Material shaft
stainless steel
Mechanical seal
PTFE/carbon, oxide ceramics, HC, FFKM

Dimensions and weight

Weight
4.42 kg
Connection outlet
External thread G 1 1/4"
Outer diameter
41,00 mm
Immersion length
1,200 mm

Approvals

3-A version
No
Ex marking
Ex II 1/2 G Ex h IIB T4…T3 Ga/Gb
For use in hazardous areas
Yes
FDA approval
no
Food approval
no

Other

Type impeller
axial impeller 34 for higher delivery rate
Drum pump type
FP 425

Compare the versions

Only the properties that differ are shown.

PropertyFP 425 Ex S-41/34 | FFKMFP 425 Ex S-41/34 | FFKMThis page
Item no.10-4252911110-42529113
Immersion length1,000 mm1,200 mm
Weight3.8 kg4.42 kg

Media

This product is suitable for 246 media. The list is a guide for common applications.

A

Is your medium not listed? Other media are often possible too. Request a quote and we will advise you personally.
