F 424 PP-41/36 | EPDM

sealless, for pumping out of canisters. Made from polypropylene, EPDM seal, shaft made from HC.

Item no.: 10-42448007

Max. flow rate: 205 l/min
Max. discharge head: 13 mWk
Material: Polypropylene

Immersion length

700 mm
1000 mm

Questions? Call +31 (0)316 29 66 90 · ma t/m do 08:00–17:00, vr 08:00–15:45

Overview

The F 424 drum pump has no seals in the liquid area and is ideal for pumping a huge range of different low-viscosity and even aggressive media. It is suited to media which flow quickly and don’t harden or crystallise and aren't abrasive. It can be used to empty canisters & hobbocks (immersion length 700 mm). Exclusively from FLUX: The specific design featuring a spiral-shaped guide bearing in the inner tube prevents unwanted deposits in the drum pump and significantly extends the pump’s service life. Radial seals prevent vapours and liquid from entering the coupling area. The drum pump is made from polypropylene. If necessary, the drum pump can also be combined with different motors.

Benefits

No seal wear
Optimum emptying of the inner tube
Long service life
Guide bearing and shaft experience little wear
Long bearing lives
Can be operated temporarily against a closed valve (pump nozzle, ball cock, etc.), up to stated max. operating temperature

Technical data

Performance

Max. flow rate: 205 l/min
Max. discharge head: 13 mWk
Max. viscosity: 1,200 mPas

Materials and sealing

Material impeller: ethylene tetrafluoroethylene
Seal material: EPDM
Material: Polypropylene
Material shaft: Hastelloy C
mechanical seal: without

Dimensions and weight

Weight: 0.79 kg
Connection outlet: External thread G 1 1/4"
Outer diameter: 40,00 mm
Immersion length: 700 mm

Approvals

3-A version: No
For use in hazardous areas: No
FDA approval: no
Food approval: no
Ex-marking: without

Other

Type impeller: axial impeller 36 for higher delivery rate
Drum pump type: F 424

Compare the versions

Only the properties that differ are shown.

Property	F 424 PP-41/36 \| EPDMThis page	F 424 PP-41/36 \| EPDM
Item no.	10-42448007	10-42448010
Immersion length	700 mm	1,000 mm
Weight	0.79 kg	0.99 kg

Media

This product is suitable for 187 media. The list is a guide for common applications.

A

Acetic acid10% · 20 °C
Acetic acid10% · 40 °C
Acetic acid25% · 20 °C
Ammonia solution100% · 20 °C
Ammonia solution100% · 40 °C
Ammonium nitrate10% · 20-40 °C
Ammonium nitrate50% · 20-40 °C
Ammonium phosphate10% · 20-40 °C
Ammonium sulphate10% · 20 °C
Ammonium sulphate10% · 40 °C
Arsenic acid10% · 20-40 °C
Arsenic acid80% · 20-40 °C

B

Battery acid40% · 20-40 °C
Benzyl alcohol100% · 20 °C
Bicarbonate of soda10% · 20 °C
Bicarbonate of soda10% · 40 °C
Bleach10% · 20 °C
Bleach20% · 20 °C
Bleach, 12%5% · 20 °C
Bleaching solution10% · 20 °C
Bleaching solution20% · 20 °C
Bleaching solution, 12%5% · 20 °C
Borax10% · 20-40 °C
Borax100% · 20-40 °C

Is your medium not listed? Other media are often possible too. Request a quote and we will advise you personally.
