Drum and container pumps

F 310 PP-32/25 | FKM

with permanently fitted motor, for pumping out of small containers, made from polypropylene, with mechanical seal, FKM seal.

Item no.
10-31042005
EAN
4260387213509
Motor type
F 310
Max. flow rate
48 l/min
Max. discharge head
6.9 mWk
Rated output
0.23 kW
Supply voltage
230-240 V
Material
Polypropylene, polyamide

Immersion length

length

Overview

With larger outer tube and rotor for a greater pump capacity. The small JUNIORFLUX F 310 drum pump with permanently fitted, powerful commutator motor, mains connection and mechanical seal is perfectly suited to filling comparatively small quantities out of containers such as canisters (immersion length 500 mm). The small outer tube diameter enables it to pump out of tight openings too. It comes with an ergonomically designed handle and low weight. There is an attachment hook for the pump nozzle on the pressure connector and an integrated bracket for mounting the pump.

Benefits

  • Minimal effort required when changing drums
  • With mains connection – very long operating period possible
  • Good operational safety thanks to overload safety switch
  • Motor with simple one-handed operation

Technical data

Performance

Max. flow rate
48 l/min
Max. discharge head
6.9 mWk
Max. viscosity
250 mPas
Nominal speed
9500 U/min | rpm
Max. medium temperature
45 °C

Electrical

Con. motor/pump
firmly connected
Cooling
internal ventilated
Nominal current
1,2 A
Rated output
0.23 kW
Protection class
IP 24
Speed control
2 steps
Supply voltage
230-240 V
Current type
AC (alternating current)
Motor type
F 310
Version motor
commutator motor
Including motor
yes
Cable length
5,00 m
Frequency
50-60 Hz
Motor protect.switch
yes
Starting current
3,00 A
Type plug
CEE 7/17-plug
Undervoltage prot.
no

Materials and sealing

Material impeller
ethylene tetrafluoroethylene
Seal material
FKM
Material
Polypropylene, polyamide
Material shaft
Hastelloy C

Dimensions and weight

Weight
1.8 kg
Connection outlet
external thread G 1"
Outer diameter
32,00 mm
Immersion length
500 mm
Nominal torque
0,15
Length
729 mm

Approvals

For use in hazardous areas
No
UL approval
no

Other

Type impeller
25
Ambient temp. max.
40 °C
Ambient temp min.
-20 °C
Drum pump type
F 310
Version drum pump
with mechanical seal
GS approved
yes
VDE approved
yes
customized product
without
other JUNIORFLUX
without

Compare the versions

Only the properties that differ are shown.

PropertyF 310 PP-32/25 | FKMThis pageF 310 PP-32/25 | FKMF 310 PP-32/25 | FKM
Item no.10-3104200510-3104200710-31042010
Immersion length500 mm700 mm1,000 mm
Weight1.8 kg2.07 kg2.24 kg
Length729 mm929 mm1229 mm

Media

This product is suitable for 180 media. The list is a guide for common applications.

A

B

C

Is your medium not listed? Other media are often possible too. Request a quote and we will advise you personally.
