Accessories

CEE round plug

5-pin, 380-415 V, 16 A

  • ATEX

Available in 2 versions

Choose a version
Material
plastic

Versions

2 versions. Choose a version to see its article number and request a quote for exactly that article.

Weight

Max. outer diameter

Colour

  • CEAG

    10-93701029

    Weight
    0.33 kg
    Max. outer diameter
    21 mm
    Colour
    red
    Pole number
    5
    Rated operat. volt.
    415 V

  • CEAG

    10-93701030

    Weight
    0.22 kg
    Max. outer diameter
    19,00 mm
    Colour
    blue
    Pole number
    3
    Rated operat. volt.
    250 V

Overview

Explosion hazard zone label: II 2 G Ex db eb IIC/IIB+H2 T6 Rated operating voltage AC: 690 V Frequency range: up to 400 Hz Area of use (zone): 1 Ambient temperature: -55 °C to +55 °C Rating: IP66

Technical data

Electrical

Protection class
IP 66
Type plug
Ex-CEE-plug Typ CEAG, 220-240 V, 3-pins
other plugs
without

Materials and sealing

Material
plastic

Approvals

Ex marking
II 2G Ex db eb IIC T6 Gb
For use in hazardous areas
Yes

Other

Wire cross-section
2,50 mm²
Max.curr.carr.capac.
16 A
Accessory type
plug

Media

This product is suitable for 51 media. The list is a guide for common applications.

A

B

C

E

Is your medium not listed? Other media are often possible too. Request a quote and we will advise you personally.
